Multi stage ultrasonic cleaning machine

Multi Stage Industrial Ultrasonic Cleaning Machine

LeelaSonic is a renowned manufacturer and exporter of Multi Stage Ultrasonic Cleaning Systems in India. Our industrial degreaser systems are designed for high-precision cleaning of automotive parts, bearings, molds, and electroplating components.

Using the latest MOSFET / IGBT technology, our machines penetrate minute crevices to remove grease, oil, rust, and wax that conventional cleaning methods cannot reach.

Get a Quote for Multi Stage Cleaner

Key Features

  • Micro-controller based Digital Timer & Temperature Control.
  • Latest MOSFET / IGBT technology for power saving.
  • Auto Degassing function for effective cleaning.
  • Rugged Stainless Steel (SS 304/316) housing.
  • Multiple Frequencies: 25 kHz / 33 kHz / 40 kHz.
  • Modular generator for easy servicing.

Advantages

  • Substantially reduces labor costs and time (No manual scrubbing).
  • Cleans blind holes and complex geometries perfectly.
  • Extends the life of parts and molds.
  • Environmentally friendly aqueous cleaning process.

Applications

  • Automotive Engine Parts & Fuel Injectors
  • Electroplating & Surface Finishing
  • Brass & Metal Parts Degreasing
  • Wire Drawing Dies
  • Surgical Instruments
  • Ball Bearings Cleaning
  • PCB & Electronics Assembly
  • Injection Molds & Tools
  • Pharma Laboratory Glassware
  • Marine Wire Mesh Filters

Models & Specifications

Model Tank Size (mm) Capacity (Liters)
LeelaSonic - 600500 x 300 x 25038
LeelaSonic - 1000600 x 400 x 40096
LeelaSonic - 1500750 x 400 x 400120
LeelaSonic - 2000900 x 500 x 500225

* Custom sizes available for specific industrial requirements.

The Multi-Stage Process

Stage 1: Ultrasonic Cleaning Removes heavy grease, oil, and dirt using cavitation.
Stage 2: Rinsing Chamber Removes detergent residue with water agitation.
Stage 3: Drying Chamber Hot air drying to ensure moisture-free parts.
Two stage ultrasonic cleaning machine

Two Stage Cleaning Machine

Three stage industrial cleaning machine

Three Stage Industrial System
